LED rear light Canbus proof 12v - 1m cable | VC-4600CAN
ECE
Fristom

LED rear light Canbus proof 12v - 1m cable | VC-4600CAN

Artikelcode: VC-4600CANEAN: 5907556018051
Aanhanger (klein)Aanhanger

€ 54,44

Prijs incl. btw · € 44,99 prijs excl. btw

3 op voorraad

Bestel vóór 16:00 — verzending volgende werkdag

+ verzending vanaf € 7,50 · gratis vanaf € 350,00

Europese voorraad
Technisch advies
14 dagen retour
Korting vanaf 10 stuks

Omschrijving

This LED rear light from Fristom s VC-4600 serie is suitable for applications with a standard on-board voltage of 12 V. It is a surface-mounted model with an open wire end and a cable length of 100 cm. The housing and lens are made of polycarbonate, which contributes to resistance to mechanical influences in demanding conditions. This rear light combines the functions: rear light, brake light and indicators. Thanks to its IP68 rating, the product is completely dust- and waterproof. The VC-4600CAN complies with CE, ECE R10, ECE R148 and ECE R150 directives, allowing deployment within European vehicle applications. Plus points of this series: - Various connectors available - Multifunctional rear light with all necessary functions - CANbus proof variants available within the series - Unique neon-look design

Specificaties

General

Voltage
12v
IP rating
IP68
Certifications
CE, ECE-R10, ECE-R148, ECE-R150
Warranty
2 jaar

Dimensions

Dimensions
240 x 140 x 58mm
Width
240mm
Depth
58mm
Height
140mm
Centre-to-centre
152mm
Shape
Rectangular

Materials

Housing colour
Black
Housing material
Polycarbonate
Lens material
Polycarbonate

Technical

Connector
Open wire end
Cable length
100cm kabel
Mounting
Surface mounting
Side
Universal

Other

tail functions
Achterlicht, Knipperlicht, Remlicht
