LED work light | 5600 lumen | 60 watts | IP69K | Deutsch | WF-6056
ECE
TRALERT®

LED work light | 5600 lumen | 60 watts | IP69K | Deutsch | WF-6056

Artikelcode: WF-6056EAN: 8718801938300
VrachtwagenAanhangerTractorGraafmachine4x4

€ 141,16

Prijs incl. btw · € 116,66 prijs excl. btw

Op voorraad

Bestel vóór 16:00 — verzending volgende werkdag

+ verzending vanaf € 7,50 · gratis vanaf € 350,00

Europese voorraad
Technisch advies
14 dagen retour
Korting vanaf 10 stuks

Doosvoordeel

Bestel een complete doos van dit product en bespaar direct.

Geldt per identiek artikel — kies dezelfde SKU. Doos direct vanuit voorraad geleverd.

Omschrijving

The TRALERT® WF-6056 is part of the Edge serie and is an LED work light designed for applications where wide light distribution is essential. This flood beam delivers a light output of 5,600 lm and operates within a voltage range of 9-36 V. The built-in Deutsch connector allows quick and reliable connection without additional cables. The sturdy aluminium housing and an impact-resistant polycarbonate lens ensure durability under harsh conditions. With an IP69K rating, this LED work light is fully protected against dust and high-pressure cleaning. Its dimensions of 137 x 90 x 67.5 mm make it suitable for mounting in compact positions. The light meets CE, ECE R10 and CISPR25 Class 3 standards. Plus points of this series: Extremely compact and flexibly mountable Powerful wide beam 5600 lumens Built-in DT-connector or cable with Deutsch-connector connector Two different mounting angles 35° and 48°

Specificaties

General

Voltage
9-36v
Wattage
60 Watt
Lumen
5600 lumens
IP rating
IP69K
Certifications
CE, CISPR25Class3, ECE-R10
Warranty
2 jaar

Dimensions

Dimensions
137 x 90 x 67.5mm
Width
137mm
Depth
67, 5mm
Height
90mm
Shape
Rectangular

Optics

Light pattern
Flood beam
Light range
76 lux@ 10m / 1.00 lux@ 88m

Materials

Housing colour
Black
Housing material
Aluminium
Lens colour
Transparent
Lens material
Polycarbonate

Technical

Connector
Built-in Deutsch connector
Cable length
N/A
Mounting
Surface mounting

Other

num leds
6 x 10W Osram LEDs
height incl base
124, 5mm
