LED-markeringslamp, amber, 24 V, 2-pins AMP MCP 2.8, Volvo-Renault | 198620
Dit amberkleurige LED-markeringslicht uit de SMD00 Vignal-serie is ontworpen voor inbouwmontage op voertuigen met een 24 V-elektrisch systeem en is met name geschikt voor Volvo en Renault. De
€ 33,77
Prijs incl. btw · € 27,91 prijs excl. btw
14 op voorraad
Bestel vóór 16:00 — verzending volgende werkdag
+ verzending vanaf € 7,50 · gratis vanaf € 350,00
Omschrijving
Specificaties
General
- Voltage
- 24v
- IP rating
- IP67
- Certifications
- CE, ECE-R10, ECE-R3, ECE-R91
- Warranty
- 2 jaar
Dimensions
- Dimensions
- 102 x 54mm
- Width
- 102mm
- Height
- 54mm
- Shape
- Rectangular
Optics
- Light colour
- Amber
Materials
- Housing colour
- White
- Housing material
- Polycarbonate
- Lens colour
- Amber
- Lens material
- Polycarbonate
Technical
- Connector
- 2-PIN AMP MCP 2.8
- Cable length
- N/A
- Mounting
- Flush mounting
