LED driving lights dark-look/black 12-24v / 14,000lm
ECE
TRALERT®

LED driving lights dark-look/black 12-24v / 14,000lm

Artikelcode: WD-13013EAN: 8720364583286
VrachtwagenBedrijfswagen4x4

€ 237,45

Prijs incl. btw · € 196,24 prijs excl. btw

Op voorraad

Bestel vóór 16:00 — verzending volgende werkdag

+ verzending vanaf € 7,50 · gratis vanaf € 350,00

Europese voorraad
Technisch advies
14 dagen retour
Korting vanaf 10 stuks

Doosvoordeel

Bestel een complete doos van dit product en bespaar direct.

Geldt per identiek artikel — kies dezelfde SKU. Doos direct vanuit voorraad geleverd.

Omschrijving

The TRALERT® Phantom serie LED driving light is designed for applications where high light output and robustness are required. This LED driving light with Driving Beam light image is suitable for use on vehicles in the voltage range 9-36 V and delivers up to 12,000 lm. With a housing made of aluminium and a polycarbonate lens, this model can withstand harsh conditions, while its IP68 rating guarantees optimal protection against dust and water. The standard 6-PIN Deutsch connector and 300 cm cable simplify installation. The driving lights have dimensions of 171x159x73 mm and are attached via surface mounting. Thanks to the white and amber coloured position lights with duo-color function, the lighting visually matches other contour lights on the vehicle. This LED driving light meets the requirements of CE, ECE-R10, ECE-R148 and ECE-R149. Plus points of this series: - LED driving lights with unique design - Equipped with duo-color position lights, matching the rest of your contour lights - Powerful light output of up to 16,000 lumen - Fully certified and made of high-quality materials

Specificaties

General

Voltage
9-36v
Wattage
140 W
Power consumption
12V: 11.3A / 24V: 5.44A
Lumen
12, 000 lumens
IP rating
IP68
Certifications
CE, ECE-R10, ECE-R148, ECE-R149
Warranty
3 jaar

Dimensions

Dimensions
171 x 159 x 73mm
Width
171mm
Depth
73mm
Height
159mm
Shape
Round

Optics

Light colour
Amber, white
Light pattern
Driving Beam
Flash function
No

Materials

Housing colour
Black
Housing material
Aluminium
Lens colour
Transparent
Lens material
Polycarbonate

Technical

Connector
6-PIN Deutsch connector
Cable length
300cm kabel
Mounting
Surface mounting
Reference number
45

Other

height incl base
171mm

Video

Documenten

  • pdfLeaflet Phantom Series 2025 ENOpenen
  • pdfDatasheet Phanton 7inch WD 13013 ENGOpenen
  • pdfLeaflet Phantom Series 2025 NLOpenen
  • pdfDatasheet Phanton 7inch WD 13013Openen
  • pdfLeaflet Phantom Series 2025 DE 1Openen
  • pdfDatasheet Phanton 7inch WD 13013 DEOpenen
  • pdfLeaflet Phantom Series 2025 FR 1Openen
  • pdfLeaflet Phantom Series 2025 ITOpenen
  • pdfDatasheet Phanton 7inch WD 13013 ITOpenen
