LED Ypsilon 9LED amber-white with warning light 7850lm - 3m cable | WD-12078.1
€ 244,01
Prijs incl. btw · € 201,66 prijs excl. btw
Op voorraad
Bestel vóór 16:00 — verzending volgende werkdag
+ verzending vanaf € 7,50 · gratis vanaf € 350,00
Doosvoordeel
Bestel een complete doos van dit product en bespaar direct.
Geldt per identiek artikel — kies dezelfde SKU. Doos direct vanuit voorraad geleverd.
Omschrijving
Specificaties
General
- Voltage
- 9-36v
- Wattage
- 120 Watt
- Power consumption
- 12 Volt / 10A - 24 Volt / 5A
- Lumen
- 7800 lumens
- IP rating
- IP68
- Certifications
- CE, ECE-R10, ECE-R148, ECE-R149
- Warranty
- 3 jaar
Dimensions
- Dimensions
- ø214 x 71mm
- Width
- 214mm
- Depth
- 71mm
- Height
- 214mm
- Shape
- Round
Optics
- Light colour
- Amber, white
- Light pattern
- Driving Beam
- Light range
- 10 lux@ 130m / 1 lux@ 490m
- Flash function
- Yes
- Flash patterns
- 4
- Flash pattern type
- Flashing
Materials
- Housing colour
- Black
- Housing material
- Aluminium
- Lens colour
- Transparent
- Lens material
- Polycarbonate
Technical
- Connector
- 6-PIN Deutsch connector
- Cable length
- 330cm kabel
- Mounting
- Surface mounting
- Reference number
- 30
Other
- height incl base
- 237mm
