Phantom Series LED driving lights dark-look black 12-24v - 16,000lm
ECE
TRALERT®

Phantom Series LED driving lights dark-look black 12-24v - 16,000lm

Artikelcode: WD-16016EAN: 8720364581947
Vrachtwagen

€ 275,26

Prijs incl. btw · € 227,49 prijs excl. btw

Op voorraad

Bestel vóór 16:00 — verzending volgende werkdag

+ verzending vanaf € 7,50 · gratis vanaf € 350,00

Europese voorraad
Technisch advies
14 dagen retour
Korting vanaf 10 stuks

Doosvoordeel

Bestel een complete doos van dit product en bespaar direct.

Geldt per identiek artikel — kies dezelfde SKU. Doos direct vanuit voorraad geleverd.

Omschrijving

This LED driving light from TRALERT®'s Phantom serie is designed for use on vehicles within the voltage range 9-36 V. With a light output of 16,000 lm and a Driving Beam light image, this driving light offers broad and efficient lighting, suitable for work in dark conditions. The dual light colour - amber and white - allows flexible application as part of your position lights or combined signal lighting. The driving light features a robust aluminium housing, a polycarbonate lens and is connected via a 6-PIN Deutsch connector with a 300 cm cable. Thanks to its IP68 rating, the product is protected against dust and long-term immersion. The Phantom driving light meets CE, ECE R10, ECE R148 and ECE R149 standards, ensuring trouble-free integration into professional vehicle networks. Mounting is via surface mounting, with dimensions of 220x205x74 mm. Plus points of this series: - LED driving lights with unique design - Equipped with duo-color position lights, matching the rest of your contour lights - Powerful light output of up to 16,000 lumen - Fully certified and made of high-quality materials

Specificaties

General

Voltage
9-36v
Wattage
160 Watt
Power consumption
12V: 13.3A / 24V: 6.6A
Lumen
16, 000 lumens
IP rating
IP68
Certifications
CE, ECE-R10, ECE-R148, ECE-R149
Warranty
3 jaar

Dimensions

Dimensions
220 x 205 x 74mm
Width
220mm
Depth
74mm
Height
205mm
Shape
Round

Optics

Light colour
Amber, white
Light pattern
Driving Beam
Light range
1 Luz @ 667m
Flash function
No

Materials

Housing colour
Black
Housing material
Aluminium
Lens colour
Transparent
Lens material
Polycarbonate

Technical

Connector
6-PIN Deutsch connector
Cable length
300cm kabel
Mounting
Surface mounting
Reference number
45

Other

height incl base
218mm

Video

Documenten

  • pdfDocument 1 — NLOpenen
  • pdfDocument 2 — NLOpenen
  • pdfDocument 3 — NLOpenen
  • pdfLeaflet Phantom Series 2025 NLOpenen
  • pdfLeaflet Phantom Series 2025 ENOpenen
  • pdfLeaflet Phantom Series 2025 ITOpenen
  • pdfLeaflet Phantom Series 2025 DEOpenen
  • pdfLeaflet Phantom Series 2025 FROpenen
