Tralert Atlas 220 driving lights duo-colour position lights 12-24v
ECE
TRALERT®

Tralert Atlas 220 driving lights duo-colour position lights 12-24v

Artikelcode: WD-5860EAN: 8720364584146
Vrachtwagen

€ 162,84

Prijs incl. btw · € 134,58 prijs excl. btw

Op voorraad

Bestel vóór 16:00 — verzending volgende werkdag

+ verzending vanaf € 7,50 · gratis vanaf € 350,00

Europese voorraad
Technisch advies
14 dagen retour
Korting vanaf 10 stuks

Doosvoordeel

Bestel een complete doos van dit product en bespaar direct.

Geldt per identiek artikel — kies dezelfde SKU. Doos direct vanuit voorraad geleverd.

Omschrijving

This LED driving light from the Atlas serie from TRALERT® is designed for use on vehicles within a voltage range of 10-30 V. Thanks to the Driving Beam, it offers a balanced combination of wide-angle and distance lighting. The light output is 6,000 lm and the driving light is equipped with amber coloured and white position lights as standard. Both the housing and the lens are made of polycarbonate for increased impact resistance and durability. Mounting is via surface mounting and connection is via an open wire end with an integrated 300cm cable. The driving light meets CE, ECE R10, ECE R148 and ECE R149 standards and has an IP69K rating, making it suitable for applications in demanding environments. Plus points of this series: - Driving lights in popular dimensions - Equipped with duo-color position lights as standard - Optionally available with built-in R65 LED warning lights - RFT lens technology for an ideal beam

Specificaties

General

Voltage
10-30v
Wattage
58 Watt
Power consumption
12V: 2.85A / 24V: 1.38A
Lumen
6000 lumens
IP rating
IP69K
Certifications
CE, ECE-R10, ECE-R148, ECE-R149
Warranty
3 jaar

Dimensions

Dimensions
250 x 137 x 89.2mm
Width
250mm
Depth
89, 2mm
Height
137mm
Shape
Rectangular

Optics

Light colour
Amber, white
Light pattern
Driving Beam
Light range
0 lux @ 280m
Flash function
No

Materials

Housing colour
Black
Housing material
Polycarbonate
Lens colour
Transparent
Lens material
Polycarbonate

Technical

Connector
Open wire end
Cable length
300cm kabel
Mounting
Surface mounting
Reference number
25

Video

Documenten

  • pdfDatasheet Altas 220 WD 5860 ENOpenen
  • pdfAtlas Series leaflet ENOpenen
  • pdfDatasheet Altas 220 WD 5860 NLOpenen
  • pdfAtlas Series leaflet NLOpenen
  • pdfDatasheet Altas 220 WD 5860 DEOpenen
  • pdfAtlas Series leaflet DEOpenen
  • pdfDatasheet Altas 220 WD 5860A FROpenen
  • pdfAtlas Series leaflet FROpenen
  • pdfDatasheet Altas 220 WD 5860 ITOpenen
  • pdfAtlas Series leaflet ITOpenen
