Atlas 320 LED driving lights | amber-white 3000 lumen | 48 Watt | 3m. cable | WD-4830
ECE
TRALERT®

Atlas 320 LED driving lights | amber-white 3000 lumen | 48 Watt | 3m. cable | WD-4830

Artikelcode: WD-4830EAN: 8720364581015
VrachtwagenBedrijfswagen4x4

€ 172,92

Prijs incl. btw · € 142,91 prijs excl. btw

Op voorraad

Bestel vóór 16:00 — verzending volgende werkdag

+ verzending vanaf € 7,50 · gratis vanaf € 350,00

Europese voorraad
Technisch advies
14 dagen retour
Korting vanaf 10 stuks

Doosvoordeel

Bestel een complete doos van dit product en bespaar direct.

Geldt per identiek artikel — kies dezelfde SKU. Doos direct vanuit voorraad geleverd.

Omschrijving

The TRALERT® Atlas serie LED driving lights are designed for applications where a powerful and focused light image is required. With a Driving Beam light pattern, this LED driving lights delivers 3,000 lm of light output in both amber coloured and white light. With a voltage range of 9-36 V, the product is suitable for a variety of vehicles in both the low and high voltage segments. The housing is made of graphene, which provides mechanical strength and good thermal features, combined with an impact-resistant polycarbonate lens. The driving light features open wire end connection and is fitted with a 300 cm cable. The housing has the highest IP value, IP69K, and the product complies with CE, ECE R10, ECE R148, ECE R149 and CISPR25 Class 5 standards. Plus points of this series: - Driving lights in popular dimensions - Equipped with duo-color position lights as standard - Optionally available with built-in R65 LED warning lights - RFT lens technology for an ideal beam

Specificaties

General

Voltage
9-36v
Wattage
48 Watt
Lumen
3000 Lumen
IP rating
IP69K
Certifications
CE, CISPR25Class5, ECE-R10, ECE-R148, ECE-R149
Warranty
2 jaar

Dimensions

Dimensions
244.4 x 138.4 x 110mm
Width
244, 4mm
Depth
110mm
Height
138, 4mm
Shape
Oval

Optics

Light colour
Amber, white
Light pattern
Driving Beam
Light range
1 Lux @ 275m
Flash function
No

Materials

Housing colour
Black
Housing material
Graphene
Lens colour
Transparent
Lens material
Polycarbonate

Technical

Connector
Open wire end
Cable length
300cm kabel
Mounting
Surface mounting
Reference number
25

Other

height incl base
177, 5mm

Video

Documenten

  • pdfDocument 1 — nlOpenen
  • pdfAtlas Series leaflet ENOpenen
  • pdfDocument 3 — nlOpenen
  • pdfAtlas Series leaflet NLOpenen
  • pdfAtlas Series leaflet DEOpenen
  • pdfAtlas Series leaflet FROpenen
  • pdfAtlas Series leaflet ITOpenen
