LED compact combination light | 12-24v | 2m cable | VC-4300
ECE
Horpol

LED compact combination light | 12-24v | 2m cable | VC-4300

Artikelcode: VC-4300EAN: 5901958828317
Aanhanger (klein)Aanhanger

€ 28,23

Prijs incl. btw · € 23,33 prijs excl. btw

6 op voorraad

Bestel vóór 16:00 — verzending volgende werkdag

+ verzending vanaf € 7,50 · gratis vanaf € 350,00

Europese voorraad
Technisch advies
14 dagen retour
Korting vanaf 10 stuks

Omschrijving

The Horpol VC-4300 serie is a compact range of LED rear lights designed for application on vehicles within the voltage range of 12-24 V. Thanks to surface mounting and a cable length of 200 cm with open wire end, integration into various vehicle types is easy to perform. The housing and lens are made of polycarbonate, which contributes to high impact resistance and environmental protection. This rear light combines the functions: rear light, brake light and indicators. With dimensions of 200x70x30 mm, this LED rear light solution is suitable for vehicles with limited space for lighting elements. The unit meets IP68 rating and is certified to CE, ECE R10, ECE R3, ECE R6 and ECE R7. Plus points of this series: - Very compact combination rear light - Useful for vehicles with limited installation space

Specificaties

General

Voltage
12-24v
IP rating
IP68
Certifications
CE, ECE-R10, ECE-R3, ECE-R6, ECE-R7
Warranty
2 jaar

Dimensions

Dimensions
200 x 70 x 30mm
Width
200mm
Depth
30mm
Height
70mm
Centre-to-centre
90mm
Shape
Rectangular

Materials

Housing colour
Black
Housing material
Polycarbonate
Lens material
Polycarbonate

Technical

Connector
Open wire end
Cable length
200cm kabel
Mounting
Surface mounting
Side
Universal

Other

tail functions
Achterlicht, Knipperlicht, Remlicht
