LED dark-look rear lights chrome 12-24v 100cm cable, flush mounting
€ 44,87
Prijs incl. btw · € 37,08 prijs excl. btw
12 op voorraad
Bestel vóór 16:00 — verzending volgende werkdag
+ verzending vanaf € 7,50 · gratis vanaf € 350,00
Omschrijving
Specificaties
General
- Voltage
- 12-24v
- IP rating
- IP69K
- Certifications
- CE, ECE-R10, ECE-R148
- Warranty
- 2 jaar
Dimensions
- Dimensions
- ø155 x 12 / 39mm - incl. VAC-4920: ø 155 x 47mm
- Width
- 155mm
- Depth
- 12mm
- Height
- 155mm
- Centre-to-centre
- 45mm
- Shape
- Round
Materials
- Housing colour
- Chrome
- Housing material
- Polycarbonate
- Lens colour
- Dark look
- Lens material
- Polycarbonate
Technical
- Connector
- Open wire end
- Cable length
- 100cm kabel
- Mounting
- Flush mounting (with VAC-4920 surface-mounted)
- Side
- Universal
Other
- cutout size
- ø113mm
- tail functions
- Achterlicht, Knipperlicht, Remlicht
