LED ECE-R23 work light 2929lm | 9-30v | 400cm cable
ECE
TRALERT®

LED ECE-R23 work light 2929lm | 9-30v | 400cm cable

Artikelcode: WR-1829V-4MEAN: 8720364583101
VrachtwagenAanhangerBedrijfswagenAanhanger (klein)TractorGraafmachine4x4

€ 43,35

Prijs incl. btw · € 35,83 prijs excl. btw

In nabestelling

Beschikbaar in nabestelling — doorgaans 7–14 werkdagen

+ verzending vanaf € 7,50 · gratis vanaf € 350,00

Europese voorraad
Technisch advies
14 dagen retour
Korting vanaf 10 stuks

Doosvoordeel

Bestel een complete doos van dit product en bespaar direct.

Geldt per identiek artikel — kies dezelfde SKU. Doos direct vanuit voorraad geleverd.

Omschrijving

The TRALERT® Apex series WR-1829V-4M is an LED work light designed for efficient use in a variety of work environments. Thanks to its combined light image as a flood beam and reversing light, this work light provides functional lighting in both working and manoeuvring situations. With a light output of 2,929 lm and a voltage range of 9-30 V (peak voltage up to 36 V), the model is suitable for variable electrical systems. The aluminium housing and polycarbonate lens provide a robust construction, suitable for outdoor use. The light is protected to IP69K and complies with CE, ECE-R10, ECE-R148 (R23) and CISPR25 Class 3 certification. As a result, the product is permitted as R23 LED reversing lights, among other things. The work light features an open wire end, 400 cm connection cable and is surface-mounted. The dimensions are 74.8 x 76 x 33.8 mm. Plus points of this series: - The new generation of LED work lights - Very fully certified, including ADR certification - Officially approved as R23 LED reversing lights - With rounded corners for excellent light distribution

Specificaties

General

Voltage
9-30v (peak voltage resistant to 36v)
Wattage
18 Watt
Power consumption
12V: 1.7A / 24V: 0.84A
Lumen
2929 lumens
IP rating
IP69K
Certifications
CE, CISPR25Class3, ECE-R10, ECE-R148 (R23)
Warranty
3 jaar

Dimensions

Dimensions
74.8 x 76 x 33.8mm
Width
74, 8mm
Depth
33, 8mm
Height
76mm
Shape
Square

Optics

Light pattern
Reversing lights

Materials

Housing colour
Black
Housing material
Aluminium
Lens colour
Transparent
Lens material
Polycarbonate

Technical

Connector
Open wire end
Cable length
400cm kabel
Mounting
Surface mounting

Other

num leds
12 x Osram 3030 LEDs
height incl base
95mm
